| Item | Description | Part Number | Qty | Item | Description | Part Number | Qty | |
| 1 | Cylinder | 969831 | 1 | 36 | Inlet filter Cover | 969826 | 1 | |
| 2 | Rotor Assembly | 969630 | 1 | 37 | Valve Spool | 969824 | 1 | |
| 3 | Vane Pack | 969825 | 1 | 38 | Wave Washer | 569867 | 1 | |
| 4 | Bearing | 569619 | 2 | 39 | Indicator Washer | 569724 | 1 | |
| 5 | Spacer | 569618 | 2 | 40 | Plug Plastic 3” | 568030 | 2 | |
| 6 | Fitting 1/8” to 4mm | 569947 | 4 | 41 | Flange 3” NPT | 969329 | 2 | |
| 7 | Plug 1/8” | 569726 | 2 | 42 | Fan for CCW Pump | 969854 | 1 | |
| 8 | Plug ½” | 569839 | 5 | Fan for CW Pump | 969856 | 1 | ||
| 9 | Bearing Retainer | 969606 | 2 | 43 | Fan Mounting Boss | 569634 | 1 | |
| 10 | Bearing Spring | 569613 | 4 | 44 | Screw M6 * 16 | 577711 | 7 | |
| 11 | Seal | 569607 | 4 | 45 | Grub Screw M8 * 20 | 569669 | 2 | |
| 12 | Screw M8 * 25 | 11063 | 28 | 46 | Oil Pump Coupler | 969829 | 1 | |
| 13 | Circlip | 569682 | 2 | 47 | Roll Pin | 569666 | 1 | |
| 14 | Shim Gasket | 569668 | * | 48 | Fan Case | 969837 | 1 | |
| 15 | O-Ring | 569683 | 2 | 49 | Fan Guard | 969836 | 1 | |
| 16 | Screw M12 * 30 | 569667 | 12 | 50 | Rubber Plug | 969834 | 2 | |
| 17 | Dowel Pin | 503259 | 4 | 51 | Screw Countersunk 1/2” * 1 | 569663 | 4 | |
| 18 | End Cover | 969605 | 2 | 52 | Screw M8 * 12 | 569662 | 14 | |
| 19 | O-Ring | 568222 | 4 | 53 | Cowling Inlet Side | 969847 | 1 | |
| 20 | Vacuum Relief Valve | 569023 | 1 | 54 | Cowling Exhaust Side | 969846 | 1 | |
| 21 | Valve Handle | 969827 | 1 | 55 | Flushing Port Sticker | 569866 | 1 | |
| 22 | Valve Cap | 968035 | 1 | 56 | Dowel Pin | 575111 | 2 | |
| 23 | Valve Cap Gasket | 568044 | 1 | 57 | Pump Model Tag | 569901 | 1 | |
| 24 | Seal | 501015 | 1 | 58 | Warning Sticker | 569903 | 1 | |
| 25 | Inlet Filter | 969821 | 1 | 59 | Rivets | 23061 | 4 | |
| 26 | Inlet Filter Cover Knob | 969842 | 2 | 60 | Screw M12 * 40 | 569852 | 4 | |
| 27 | Stud M10 | 969822 | 2 | 61 | Foot | 969823 | 2 | |
| 28 | Check Valve | 969841 | 1 | 62 | Cable Tie | 503054S | 3 | |
| 29 | Nut M10 | 26066 | 2 | 63 | Oil Line | 600293 | * | |
| 30 | Shoulder Screw M12 * 40 | 569851 | 1 | 64 | PVC Tube | 24294 | 2 | |
| 31 | Screw M8 * 60 | 569849 | 7 | 65 | Oil Pump | 569636 | 4 | |
| 32 | Screw M10 * 35 | 501966 | 5 | 66 | Banjo Fitting M8 * 1 to 4mm | 569409 | 1 | |
| 33 | Valve Exhaust Gasket | 969832 | 1 | 67 | Plug Plastic 1/16” | 568008 | 1 | |
| 34 | Valve Inlet Gasket | 969833 | 1 | 68 | Oil Pump Supply Fitting | 569859 | 1 | |
| 35 | Valve Body | 969838 | 1 | 69 | Oil Pump Cap | 969828 | 1 |
